Viscosity Model

Name: Viscosity Model
Brand: SAMTECH INSTRUMENTS
Price: 650.0 INR
Availability: InStock

Price 650.0 INR/ Piece

Get a Price/Quote

MOQ : 50 Pieces

Viscosity Model Specification

Measurement Range
10~2,000,000 mPas

Frequency
50/60 Hz

Accuracy
1.0% of Full Scale

Temperature Range
Room Temperature to 100C

Automation Grade
Automatic

Voltage
220V

Feature
High Accuracy, Digital Display, Easy to Operate

Core Components
Motor, Display Panel, Sensor

Model No
PHY-144

Power Source
Electric

Capacity
10-1000 ml

Equipment Materials
Stainless Steel, ABS Plastic

Type
Rotational Viscometer

Usage
Laboratory, Industrial

Display Type
Digital

Dimension (L*W*H)
370 x 325 x 280 mm

Weight
7 kg

Application
Oils, Paints, Chemicals, Inks, Adhesives

Operation Mode
Continuous

Environment Temperature
5C to 35C

Relative Humidity
80%

Data Output
RS232 Interface

Power Consumption
Less than 50 W

Spindle Set
No. 1-4 Standard Spindles

Storage Temperature
-10C to 50C

Speed Range
0.3 to 60 RPM

Viscosity Model About

Viscosity Tube Model

We are a leading manufacturer, supplier, and exporter of Viscosity Tube Models designed for physics laboratories, chemistry laboratories, STEM education, and classroom demonstrations. This educational apparatus helps students understand the concepts of viscosity, fluid resistance, density, and the flow characteristics of liquids through a simple and visual experiment.

The Viscosity Tube Model consists of transparent tubes filled with different liquids and sealed with floating balls. By observing the movement of the balls through various fluids, students can easily compare the viscosity and resistance offered by each liquid. This hands-on demonstration makes complex fluid mechanics concepts easy to understand and highly engaging.

Ideal for schools, colleges, universities, and science laboratories, the model provides a practical approach to studying the behavior of liquids and the factors affecting fluid flow.

Efficient and Versatile Measurement

With a rotational speed range of 0.3 to 60 RPM and four standard spindles, the PHY-144 provides versatile viscosity measurement solutions. Suitable for both laboratory and industrial environments, this viscometer can accommodate sample volumes from 10 to 1000 ml and is compatible with a wide range of substances, including oils, paints, chemicals, inks, and adhesives.

User-Friendly Digital Interface

The PHY-144 features an intuitive digital display panel that offers real-time measurement readings. Data can be conveniently exported via the RS232 interface for further analysis or record-keeping, supporting streamlined workflows and efficient data management. Its continuous operation mode and automatic grade make it easy to use for both beginners and professionals.

Durable, Reliable, and Accurate

Constructed with stainless steel and ABS plastic, the PHY-144 delivers long-lasting performance and reliability. Operating within 5C to 35C and in up to 80% relative humidity, it maintains high accuracy (1.0% full scale), ensuring dependable results even in challenging laboratory or industrial environments.

FAQ's of Viscosity Model:

Q: How does the PHY-144 Rotational Viscometer measure viscosity?

A: The PHY-144 uses a rotational mechanism with four standard spindles that rotate at speeds between 0.3 and 60 RPM. By measuring the resistance to rotation in a liquid sample (10-1000 ml capacity), the device determines viscosity digitally and displays the result in real time.

Q: What types of substances can I test with this viscometer?

A: You can use the PHY-144 to measure the viscosity of a broad range of substances such as oils, paints, chemicals, inks, and adhesives. Its wide measurement range (10-2,000,000 mPas) and compatible spindles make it suitable for many laboratory and industrial fluids.

Q: When is it recommended to use the automatic operation mode?

A: The automatic operation mode is ideal when you require consistent, hands-off viscosity measurements for multiple samples or routine testing. It ensures accurate results while saving time in high-throughput laboratory or industrial processes.

Q: Where does the data output from the viscometer go, and how is it accessed?

A: Measurement results are exported via the RS232 interface, enabling direct connection to a computer or compatible device. This allows for easy data collection, archiving, or integration with laboratory information systems for further analysis.

Q: What is the process for cleaning and maintaining the PHY-144?

A: After each use, gently remove the spindle and wash with an appropriate solvent compatible with your tested substance. The instrument's stainless steel and ABS plastic materials facilitate easy cleaning, and periodic checks on the motor and display panel help ensure long-term reliability.

Q: How does the digital display benefit users during operation?

A: The digital display provides clear, immediate readings of viscosity and relevant parameters, reducing user error and enhancing operational efficiency. This feature simplifies monitoring and documentation during continuous or repeated measurements.

Q: What are the primary benefits of using this viscometer in laboratories and industry?

A: The PHY-144 offers high accuracy, straightforward operation, digital data management, and versatility in handling diverse sample types. Its robust construction ensures durability, while automation and precise control enable reliable and repeatable measurement outcomes in demanding settings.
