Solenoid- Big

Name: Solenoid- Big
Brand: SAMTECH INSTRUMENTS
Price: 300.0 INR
Availability: InStock

Price 300.0 INR/ Piece

Get a Price/Quote

MOQ : 50 Pieces

Solenoid- Big Specification

Automation Grade
Semi-Automatic

Frequency
50/60 Hz

Feature
High Force Output, Long Life, Reliable Operation

Voltage
24V DC (other voltages available on request)

Model No
MAE-105

Temperature Range
-20C to 80C

Accuracy
High Operational Precision

Measurement Range
Stroke up to 24 mm

Core Components
Copper Winding, Iron Armature, Spring, Enclosure

Power Source
Electric

Product Type
Solenoid on Base

Capacity
Big (customized as per requirements)

Equipment Materials
Copper Coil, Iron Core, MS Housing

Type
Electromagnetic Solenoid

Usage
Industrial Automation, Actuation, Locking Mechanisms

Dimension (L*W*H)
120 mm x 65 mm x 60 mm

Weight
Approx. 1.8 kg

Lead Length
300 mm (customizable)

Rated Current
1.3A

Coil Resistance
18 Ohms 5%

Response Time
<30 ms

Duty Cycle
40% ED

Insulation Class
Class B

Surface Finish
Powder Coated

Mounting Type
Bracket Mounting Holes

Stroke Force
35N at rated voltage

Ambient Humidity
< 85% RH

Solenoid- Big Trade Information

Minimum Order Quantity
50 Pieces

Delivery Time
5-7 Days

About Solenoid- Big

Solenoid on Base

The Solenoid on Base is a laboratory demonstration model designed to illustrate the magnetic field produced by a current-carrying solenoid. The apparatus consists of a long insulated copper wire coil securely mounted on a durable base with terminal connections for easy electrical input.

When electric current passes through the solenoid, it generates a magnetic field similar to that of a bar magnet, with distinct north and south poles. This model helps students visualize how electrical energy can create magnetism and serves as an excellent teaching aid for understanding electromagnetism, magnetic fields, and the operation of electromagnetic devices.

Manufactured for classroom and laboratory use, the Solenoid on Base provides a clear and practical demonstration of one of the most important principles in physics.

High Force Output & Quick Response

The MAE-105 solenoid delivers a substantial stroke force of 35N at rated voltage with a rapid response time of less than 30 milliseconds. Its design supports applications requiring fast and precise actuation, making it ideal for critical industrial operations.

Built for Industrial Durability

Encased in a powder-coated mild steel housing, this solenoid employs copper coil and an iron core, ensuring longevity and reliable performance. With insulation class B and the ability to operate within a broad ambient temperature and humidity range, it's suitable for challenging industrial environments.

Versatile Customization Options

Whether you need different lead lengths, voltages, or capacities, the MAE-105 can be tailored to your specifications. This flexibility allows for seamless integration into both new and existing automation systems, maximizing applicability and efficiency.

FAQ's of Solenoid- Big:

Q: How is the MAE-105 solenoid typically installed?

A: The MAE-105 solenoid is designed for bracket mounting, utilizing mounting holes for secure and straightforward installation. This setup ensures stability and ease of integration into industrial fixtures or machinery.

Q: What are the typical applications of the MAE-105 solenoid?

A: This solenoid is ideal for use in industrial automation systems, actuation tasks, locking mechanisms, and applications where high force and rapid response are needed. Its robust construction and precision make it suitable for frequent use in rigorous environments.

Q: When should I consider customizing the MAE-105 solenoid?

A: Customization is recommended when specific lead lengths, voltage ratings, or force capacities are required for your application. Tailoring these parameters ensures optimal performance and compatibility with your unique operational needs.

Q: Where can the MAE-105 solenoid be effectively used?

A: Thanks to its wide ambient temperature range of -20C to 80C and suitability for humidity below 85% RH, the MAE-105 can be effectively deployed in factories, industrial automation settings, security systems, and other demanding environments.

Q: What benefits does the MAE-105 solenoid provide in industrial applications?

A: It offers high force output, long operational life, reliable actuation, and quick response, contributing to increased productivity, enhanced safety, and minimized downtime in industrial processes.

Q: How does the 40% duty cycle (ED) affect operation?

A: A 40% duty cycle means the solenoid can be energized for 40% of a cycle time, with the remaining 60% spent de-energized. This balance prevents overheating, prolongs lifespan, and ensures sustained performance under intermittent use.
